Axial fan device

                                      Hangzhou Jinjiu Electric Appliance Co.,Ltd

---

Introduction to the axial flow fan device Before the preparation device for the device, all instructions should be known to know the fan; clarify the ventilation system drawing of the fan operation; unpack the box to see if the fan components can be completely closed; whether there is any bruise on the outside of the casing; Whether the rectifier can be deformed by bumps; whether the connection of each component can be tight; whether the blade motor has damage; whether the impeller can be sensitive; if it is found, the problem should be repaired and adjusted. Check the device base of the fan. The group is through the murderer V, the mother, the sang, the singer, the singer, the singer, and the singer.
The fan device 1 and the fan horizontal device fix the damper to the fan frame through the connecting bolt; adjust the level of each damper with the middle height adjusting pad; fix the fan to the root with the fixing bolt Connected to the steel plate; if the fan does not need a damper because of the earthquake resistance, the screw hole on the fan base and the embedded bolt on the base can be directly connected.
2. The basic requirements of the horizontal wall horizontal device fan device are the same as those for the horizontal device; only the device bracket is made of oblique arm support; the bracket should have the required strength and rigidity; the fan above 10# should not use this device. .
3. The suspended device firstly connects the damper and the fan with bolts; the damper symmetrical device; is arranged on both sides of the center of gravity of the fan; directly pushes the fan into the suspension bracket; the height of the suspension bracket; Customized by the user; fans above 16# usually do not use this type of device.
4. Vertical device fan vertical device method is common with horizontal device; the strength and rigidity of the fan root are more severe.
It is necessary to use flexible joints for the connection between the fan and the two pipes to block the oscillation and keep the fan.

---
